| Modelo no.: | Se trata de una serie de medidas de seguridad. | Tipo de interfaz: | USB |
|---|---|---|---|
| Elemento de escaneo: | CMOS | Resolución de la cámara: | 640*480 |
| Resolución de código de barras: | 3mil Code39 | Profundidad de campo: | 30-600 mm |
| Modo de escaneo: | Manual, continuo, escaneo automático | Imprimir contraste: | 15% |
| UPC: | 32 bits | Longitud del cable: | 1,5 m |
| Peso: | 160 g | Fuente de alimentación: | CC 5 V 200 mA |
| Temperatura de funcionamiento: | -20 a 55 grados | Temperatura de almacenamiento: | -40 a 60 grados |
| Dimensiones: | L165.5 mm * W63.5 mm * H92.3 mm | ||
| Resaltar: | 640*480 Resolution 2D Barcode Scanner,30-600mm Depth of Field Handheld Barcode Scanner,32 Bit CPU QR Code Scanner |
||
| Parameter | Specification |
|---|---|
| Scan Type | CMOS |
| Light Source | Red Light LED 525±10nm (aim), 5600K LED (Lighting) Note: Global exposure camera with automatic brightness adjustment |
| CPU | 32-bit |
| Resolution | 640*480 |
| Minimum Resolution | ≥3mil/0.1mm (PCS90%, CODE 39) |
| Decoding Speed | 65CM/S |
| Depth of Field | 30-600mm |
| Scan View | 41° * 31° |
| Scan Mode | Manual, Continuous, Auto Sense |
| Scan Angle | Roll: ±360°, Pitch: ±60°, Yaw: ±55° |
| Print Contrast Signal | ≥15% |
| Ambient Light | Dark environment, indoor natural light |
| Supported Symbologies |
1D: UPC-A, UPC-E, EAN-8, EAN-13, Code 128, GS1-128, Code 39, Code 32, Code 93, Code 11, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, Standard 2 of 5, Codabar, MSI, GS1 Databar, China Post, Tepepen, Febraban, GS1 Composite, Japan Post 2D: QR Code, Micro QR Code, Data Matrix, PDF417, Micro PDF 417, MaxiCode, Aztec, HanXin Code |
| Weight | ≈160g (without cable) |
| Dimensions | 165.5mm (L) × 63.5mm (W) × 92.3mm (H) |
| Interface Type | USB |
| Cable Length | 1.8m |
| Power Supply | DC5V input, decoding current: 200mA |
| Operating Temperature | -20ºC to 55ºC |
| Storage Temperature | -40ºC to 60ºC |
| Humidity | 5% to 95% (non-condensing) |
| Drop Height | 1.5m |
| Temperature Test | 30 minutes for high temp. (60ºC), 30 minutes for low temp. (-20ºC) |
| Transport Vibration Test | 10H@125RPM |
